LED Wall Pack Housing MLT-WPH-DS-I

LED Wall Pack Housing MLT-WPH-DS-I

LED Wall Pack Housing MLT-WPH-DS-I

LED Wall Pack Housing MLT-WPH-DS-I

Brief Introduction

This COB LED wall pack housing fixture MLT-WPH-DS-I is the smallest size wall-mounted housing which is originally designed for COB LED light engine with die-casting aluminum heat sink in the back. We also have a smilar size wall pack housing for SMD LED wall pack named MLT-WPH-DS-II. With the latest LED lighting technology and protogenetic LED wall pack housing, the luminous flux output is much more, the efficacy is much higher and the heat dissipation is much better for a long time lifespan and less maintenance. Durable powder coating finish can withstand extreme climate changes without cracking, peeling or fading.

Feature

  • Integrated heat sink for excellent thermal management.
  • Durable aluminum die-casting housing for heavy-duty outdoor lighting applications.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • High efficacy reflector special for COB LED wall pack housing.
  • High light transmittance and shock-resistant PC prismatic diffuser.
  • Silicon foam gaskets.
  • IP65 rated, protect from all dust and harsh weather.
  • Standard bronze finish.
  • Supports Semi Cut-off Mode
  • Easy to assemble, install and maintain.

Mechanical Dimensions

LED Wall Pack Housing MLT-WPH-DS-I Mechanical Dimension

Parameter

Model No.LED Wall Pack Housing MLT-WPH-DS-I
Dimension of Housing30.8cm(L)*26.4cm(W)*18.2cm(H)
Fixture MaterialDie-casting Aluminum + PC
Surface Finish ColorBronze or Customized color
Material of DiffuserPrismatic PC
Mounting TypeWall Mount
COB LED Mounting Size34mm(L)*34mm(W)
Driver Box Dimension248mm(L)*54mm(W)*140mm(H)
Recommended Power Range30W
IP RatingIP65

Pictures

LED Wall Pack Housing MLT-WPH-DS-I Front View
LED Wall Pack Housing MLT-WPH-DS-I Front View
LED Wall Pack Housing MLT-WPH-DS-I Back View
LED Wall Pack Housing MLT-WPH-DS-I Back View

Packing Information

Net Weight7.2kg/PCS
Gross weight10kg/Carton
Quantity4PCS/ carton
Carton Size74cm(L)*41cm(W)*33.5cm(H)

Application

The COB LED wall pack housing from Moonlight is ideal for wall-mounted doorway and pathway LED wall pack lighting fixture in a variety of applications. LED wall pack are typically applied as wall-mounted security lighting, commercial lighting that are installed on the sides of buildings, warehouse, parking garages, building walkways, pedestrian walkways, and other places around commercial buildings.
