LED Wall Pack Housing MLT-WPH-CS-II

LED Wall Pack Housing MLT-WPH-CS-II

LED Wall Pack Housing MLT-WPH-CS-II

LED Wall Pack Housing MLT-WPH-CS-II

Brief Introduction

This rugged dark bronze aluminum die-casting LED wall pack housing fixture MLT-WPH-CS-II is the smallest size wall-mounted housing which is ideal for personal door security lighting. The die-cast aluminum back plea alongside the polycarbonate front cover is impact resistant and sealed against moisture and environmental contaminants. With the latest LED lighting technology and protogenetic LED wall pack housing, the luminous flux output is much more, the efficacy is much higher and the heat dissipation is much better for a long time lifespan and less maintenance. Durable powder coating finish can withstand extreme climate changes without cracking, peeling or fading.

Feature

  • Ideal for personal door security lighting.
  • Durable aluminum die-casting housing for heavy-duty outdoor lighting applications.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • High light transmittance heat and shock-resistant borosilicate glass prismatic diffuser.
  • Silicon foam gaskets.
  • Multiple knockouts for mounting convenience.
  • 1/2″ conduit openings with plugs for conduit mounting.
  • IP65 rated, protect from all dust and harsh weather.
  • Standard bronze finish.
  • PIR sensor mounting platform.
  • Easy to assemble, install and maintain.

Mechanical Dimensions

LED Wall Pack Housing MLT-WPH-CS-II Mechanical Dimension

Parameter

Model No.LED Wall Pack Housing MLT-WPH-CS-II
Dimension of Housing23.2cm(L)*15.3cm(W)*9.3cm(H)
Fixture MaterialDie-casting Aluminum+PC
Surface Finish ColorBronze or Customized color
Material of DiffuserHigh Transmittance PC
Mounting TypeWall Mount
Aluminum Substrate Mounting Size71mm(L)*36mm(W)
Driver Box Dimension116.8mm(L)*105.6mm(W)*60.5mm(H)
Recommended Power Range25W
IP RatingIP65

LED Wall Pack Wall Mounting

LED Wall Pack Housing MLT-WPH-CS-II Wall Mounting
LED Wall Pack Housing MLT-WPH-CS-II Wall Mounting

Pictures

LED Wall Pack Housing MLT-WPH-CS-II Front View
LED Wall Pack Housing MLT-WPH-CS-II Front View
LED Wall Pack Housing MLT-WPH-CS-II Back View
LED Wall Pack Housing MLT-WPH-CS-II Back View

Packing Information

Net Weight0.86kg/PCS
Gross weight7.80kg/Carton
Quantity1PCS/Box, 8Box/ Carton
Carton Size42cm(L)*34cm(W)*26cm(H)

Application

The LED wall pack housing from Moonlight is ideal for wall-mounted doorway and pathway LED wall pack lighting fixture in a variety of applications. LED wall pack are typically applied as wall-mounted security lighting, commercial lighting that are installed on the sides of buildings, warehouse, parking garages, building walkways, pedestrian walkways, and other places around commercial buildings.
