Brief Introduction

This SMD LED wall pack housing fixture MLT-WPH-DS-II is the smallest size wall-mounted housing which is originally designed for SMD LED light engine with die-casting aluminum heat sink on the back of the housing. With the latest LED lighting technology and protogenetic LED wall pack housing, the luminous flux output is much more, the efficacy is much higher and the heat dissipation is much better for a long time lifespan and less maintenance. Durable powder coating finish can withstand extreme climate changes without cracking, peeling or fading. We also have a similar LED wall pack shell, which is designed for COB type LED. This COB LED wall pack case is named MLT-WPH-DS-I. This COB LED wall pack casing has the similar size but different height.

Feature

  • Integrated heat sink for excellent thermal management.
  • Durable aluminum die-casting SMD LED wall pack housing for heavy-duty outdoor lighting applications.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • High light transmittance and shock-resistant PC prismatic diffuser.
  • Silicon foam gaskets.
  • IP65 rated, protect from all dust and harsh weather.
  • Standard bronze finish.
  • Supports Semi Cut-off Mode
  • Easy to assemble, install and maintain.

Mechanical Dimensions

LED Wall Pack Housing MLT-WPH-DS-II Mechanical Dimension

Parameter

Model No.LED Wall Pack Housing MLT-WPH-DS-II
Dimension of Housing30.8cm(L)*28.8cm(W)*12.6cm(H)
Fixture MaterialDie-casting Aluminum + PC
Surface Finish ColorBronze or Customized color
Material of DiffuserPrismatic PC
Mounting TypeWall Mount
Aluminum Substrate Mounting Size167.1mm(L)*125.9mm(W)
Driver Box Dimension248mm(L)*78mm(W)*120mm(H)
Recommended Power Range50W
IP RatingIP65

Pictures

LED Wall Pack Housing MLT-WPH-DS-II Front View
LED Wall Pack Housing MLT-WPH-DS-II Front View
LED Wall Pack Housing MLT-WPH-DS-II Back View
LED Wall Pack Housing MLT-WPH-DS-II Back View

Packing Information

Net Weight7kg/PCS
Gross weight9.8kg/Carton
Quantity4PCS/ carton
Carton Size54.5cm(L)*31.5cm(W)*33cm(H)

Application

The SMD LED wall pack housing from Moonlight is ideal for wall-mounted doorway and pathway LED wall pack lighting fixture in a variety of applications. LED wall pack are typically applied as wall-mounted security lighting, commercial lighting that are installed on the sides of buildings, warehouse, parking garages, building walkways, pedestrian walkways, and other places around commercial buildings.
