LED High Bay Housing MLT-HBH-CXL-I

LED High Bay Housing MLT-HBH-CXL-I

LED High Bay Housing MLT-HBH-CXL-I

LED High Bay Housing MLT-HBH-CXL-I

Brief Introduction

This LED high bay housing fixture MLT-HBH-CXL-I is the extra-large size of COB LED high bay housing fixture with chimney reflector from Moonlight LED high bay C series. In this warehouse lighting fixture family, there are other four models, MLT-HBH-CL-I, MLT-HBH-CM-I, MLT-HBH-CS-I and MLT-HBH-CXS-I. Modern design, high efficacy heat pipe as the core and superior Nano coating finish heatsink make this housing can be used for variety of LED commercial and industry lighting applications.


  • Phase transition heat pipe in the center of the heatsink for heavy-duty and high efficiency thermal management.
  • Nano-coating appearance enhances heat dissipation and resist corrosion, chipping and fading.
  • Extruded aluminum fins at the outside of the heatsink increased air flow velocity providing maximum passive thermal management.
  • Meanwell HLG series or similar power supplies compatibility.
  • High light transmittance glass lens for different beam angles.
  • Silicon gaskets.
  • Stainless steel bolts for fastening
  • IP65 rated, protect from all dust and harsh weather.
  • Standard black finish.
  • Safety rope is provided for security.
  • Easy to assemble, install and linemen friendly maintain.

Mechanical Dimensions

LED High Bay Housing MLT-HBH-CXL-I Mechanical Dimensions


Model No.LED High Bay Housing MLT-HBH-CXL-I
Dimension of Housing36cm(Φ)* 44.7cm(H)
Fixture MaterialCopper + Aluminum + PC
Diffuser MaterialHigh Transmittance Tempered Glass
Reflector MaterialAluminum/PC(60° only)
Surface Finish ColorBlack or Customized color
Recommended LED Power150W to 200W
Driver CompatibilityMeanwell HLG Series or Similar
Angle of Glass Lens60°/90°/120°
Angle of Chimney120°
Mounting MethodHook


LED High Bay Housing MLT-HBH-CXL-I Side View
LED High Bay Housing MLT-HBH-CXL-I Side View
LED High Bay Housing MLT-HBH-CXL-I Back View
LED High Bay Housing MLT-HBH-CXL-I Back View

Packing Information

Net Weightkg/PCS
Gross weightkg/carton
QuantityPCS/ carton
Carton Sizecm(L)* cm(W)* cm(H)


This heavy-duty, modern design, energy-efficient and cost-effective LED high bay housing fixture is typically used as 150W-200W LED high bay light. LED high bay lights are specifically designed for taller ceilings and larger areas. They focus light more directly to create powerful illumination at a long range. This makes them perfect for commercial and industrial applications such as supermarkets, exhibition halls, big-box retail stores, sporting venues, manufacturing plants, warehouses, recreation centers, hangars and storage facilities. These LED industry lighting fixtures improve visibility and worker safety while enhancing productivity.
