High Bay Light Cover MLT-HBH-FM-II

High Bay Housing MLT-HBH-FM-II

High Bay Housing MLT-HBH-FM-II

High Bay Housing MLT-HBH-FM-II

Brief Introduction

This LED high bay housing fixture MLT-HBH-FM-II is the medium size of round SMD LED high bay housing fixture from Moonlight LED high bay F series, and the weight of the high bay light housing aluminum alloy die-casting part is 2900g. In the F family LED high bay light housing, there is a smaller one named high bay housing MLT-HBH-FS-II which is made for 60W-100W SMD LED high bay. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing, make this housing can be used for variety of LED commercial and industry lighting applications. It also have a dural 80° aluminum alloy chinmey for industrial lighting application.

Feature

  • Durable aluminum alloy die-casting high bay housing for heavy-duty lighting applications.
  • Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
  • Easy drainage fins system.
  • Multiple brand power supplies compatibility.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • High light transmittance tempered glass.
  • Silicon gaskets.
  • Stainless steel bolts and hook for fastening.
  • IP65 rated, protect from all dust and harsh weather.
  • Standard black finish.
  • Multiple mounting solution for different installation applications.
  • Safety rope is provided for security.
  • Easy to assemble, install and linemen friendly maintain.

Mechanical Dimensions

High bay housing MLT-HBH-FS-II Mechanical Dimensions

Parameter

Model No. LED High Bay Light Cover MLT-HBH-FM-II
Dimension of Housing 34.3cm(φ)*5.4cm(H)
Fixture Material Die-casting Aluminum Alloy
Die-casting Aluminum Alloy Weight 2900g
Diffuser Material High Transmittance Tempered glass/PC
Surface Finish Color Black or Customized color
Effective MCPCB Mounting Size 289.80mm(Φ)
Recommended LED Power 150W to 200W
Driver Compatibility Multiple Brand
Beam Angle 80°/120°
Mounting Method Hook /Pendant /Bracket Mounting Options

Type of Mounting

LED High Bay Light Mounting Options
LED High Bay Light Mounting Options

Pictures

High Bay Housing MLT-HBH-FM-II Front View
High Bay Housing MLT-HBH-FM-II Front View
High Bay Housing MLT-HBH-FM-II Back View
High Bay Housing MLT-HBH-FM-II Back View

Application

This heavy-duty, modern design, energy-efficient and cost-effective LED high bay housing fixture is typically used as 100W-150W LED high bay light. LED high bay lights are specifically designed for taller ceilings and larger areas. They focus light more directly to create powerful illumination at a long range. This makes them perfect for commercial and industrial applications such as supermarkets, exhibition halls, big-box retail stores, sporting venues, manufacturing plants, warehouses, recreation centers, hangars and storage facilities. These LED industry lighting fixtures improve visibility and worker safety while enhancing productivity.

Packing Information

Net Weight 3.80kg
Gross weight 9kg
Box Size 36cm(L)* 36cm (W)*16cm(H)
Quantity 2boxes/ carton
Carton Size 38.5cm(L)* 38.5cm (W)*36.5cm(H)
