LED Street Light Housing MLT-SLH-BL-II

Street Light Shell MLT-SLH-BL-II

LED Street Light Housing MLT-SLH-BL-II

Street Light Shell MLT-SLH-BL-II

Brief Introduction

This LED street light shell MLT-SLH-BL-II is the large size of SMD LED street light housing fixture from Moonlight LED street light B series. In this aluminum die-casting housing family, there are other two models, MLT-SLH-BS-II and MLT-SLH-BM-II. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing with standard twist lock photocell mounting platform, make this housing can be used for variety of LED roadway lighting applications.

Data Sheet

Feature

  • Durable aluminum alloy die-casting street light shell for heavy-duty outdoor lighting applications.
  • Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
  • Easy drainage fins system.
  • Separate LED light engine and driver box for easy maintenance.
  • Tool-less design for replace the LED driver without any tool.
  • Large driver box complies with Meanwelll HVG series drivers.
  • Both cover and bottom of the driver box have the GND bosses for security.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • Adjustable knuckle slip fitter with SUS304 stainless steel hardware secures fixture to pole arm.
  • 5mm high light transmittance tempered glass diffuser.
  • Silicon gaskets.
  • SUS304 stainless steel bolts and clips for fastening.
  • Standard S6000 socket and twist lock photocell mounting platform for lighting control.
  • IP66 rated, protect from all dust and harsh weather.
  • Standard Gray finish.
  • Easy to assemble, install and linemen friendly maintain.

Mechanical Dimensions

Street Light Shell MLT-SLH-BL-II Mechanical Dimensions

Parameter

Model No. LED Street Light Shell MLT-SLH-BL-II
Dimension of Housing 98.3cm(L)*35cm(W)*11.7cm(H)
Fixture Material Die-casting Aluminum Alloy
Surface Finish Color Gray or Customized color
Material of Diffuser High Transmittance Tempered glass
Effective MCPCB Mounting Size 506.5mm(L)* 300mm(W)
Recommended LED Power 180W to 240W
Driver Box Dimension 315mm(L)* 175mm(W)* 93mm(H)
Pole Mounting Accommodates up to Φ65mm pipe
Adjustable Slip Fitter -90°to +90°
Standard Photocell Optional
IP Rating IP66

Pictures

Street Light Shell MLT-SLH-BL-II Front View
LED Street Light Housing MLT-SLH-BL-II Front View
Street Light Shell MLT-SLH-BL-II Back View
LED Street Light Housing MLT-SLH-BL-II Back View

Packing Information

Net Weight 12.72kg/PCS
Gross weight 14kg/carton
Quantity 1PCS/ carton
Carton Size 100cm(L)* 38.5cm(W)* 18cm(H)

Application

This heavy-duty, modern design and cost-effective LED street light shell fixture is typically used as 180W-240W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
