Street Light Cover MLT-SLH-HM-II

street light cover mlt-slh-hm-ii

street light cover mlt-slh-hm-ii

street light cover mlt-slh-hm-ii

Brief Introduction

This street light cover MLT-SLH-HM-II is the medium size of SMD LED street light housing fixture from LED road lamp housing factory Moonlight’s H group. In this LED street light shell family, there is also a smaller one named LED street light casing MLT-SLH-HS-II. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing with standard twist lock photocell mounting platform, make this housing can be used for variety of LED roadway lighting applications.

Feature

  • Durable aluminum alloy die-casting LED street light cover for heavy-duty outdoor lighting applications.
  • Ribbon-free and compact design.
  • Easy drainage system.
  • Separate LED light engine and driver box for easy maintenance.
  • Tool-less design for replace the LED driver without any tool.
  • Large driver box complies with variety of drivers and dimming options.
  • Both cover and bottom of the driver box have the GND bosses for security.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • Adjustable knuckle slip fitter help to adjust the led street light fixture on-site for optimal photometric performance, which make sure that the light distributions, are specifically adapted to the real needs of the area to be lit.
  • Side-entry or post-top mounting. Universal mounting pieces allows precise adjustment on-site.
  • 5mm high light transmittance tempered glass diffuser.
  • Silicon gaskets.
  • SUS304 stainless steel bolts for fastening.
  • The powder coated die-cast clips make it a harmonious overall with the rest of the luminaire.
  • Twist lock photocell mounting platform for lighting control.
  • Quick disconnection terminal block mounting platform for disconnect the power supply for linemen handling security.
  • IP66 rated, protect from all dust and harsh weather.
  • Standard sanded gray finish.
  • Easy to assemble, install and linemen friendly maintain.

Mechanical Dimensions

street light cover mlt-slh-hm-ii mechanical dimensions

Parameter

Model No. LED Street Light Cover MLT-SLH-HM-II
Dimension of Housing 67.7cm(L)*29.1cm(W)*10.6cm(H)
Fixture Material Die-casting Aluminum Alloy
Die-casting Aluminum Alloy Weight 4000g
Surface Finish Color Sanded Gray or Customized color
Material of Diffuser High Transmittance Tempered glass
Effective MCPCB Mounting Size 245mm(L)*188mm(W)
Compatible Lenses 12PCS 50mm*50mm Lenses
Recommended LED Power 100W to 150W
Driver Box Dimension 224mm(L)*70mm(W)*48mm(H)
Pole Mounting Accommodates up to Φ60mm pipe
Adjustable Slip Fitter -15°to +15°
Standard Photocell Optional
Quick Disconnection Terminal Block N/A
IP Rating IP65

Pictures

street light cover mlt-slh-hm-ii front view
street light cover mlt-slh-hm-ii front view
street light cover mlt-slh-hm-ii back view
street light cover mlt-slh-hm-ii back view

Packing Information

Net Weight 4.6kg/PCS
Gross weight 10.8kg/carton
Quantity 2PCS/ carton
Carton Size 71cm(L)*32cm(W)*30cm(H)

Application

This heavy-duty, modern design and cost-effective LED street light housing fixture is typically used as 100W-150W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
