Brief Introduction

This unique LED street light housing fixture MLT-SLH-AS-II is the smallest size of SMD LED street light housing fixture from Moonlight LED street light A series. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing with NEMA standard twist lock photocell mounting platform, make this housing can be used for variety of LED roadway lighting applications.

Feature

  • Durable aluminum alloy die-casting housing for heavy-duty outdoor lighting applications.
  • Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • Rugged heavy gauge, 4 bolt, galvanized clamp with stainless steel hardware secures fixture to pole arm.
  • 5mm high light transmittance tempered glass diffuser.
  • Silicon gaskets.
  • Stainless steel bolts for fastening
  • Standard NEMA Twist lock photocell mounting platform for lighting control.
  • IP65 rated, protect from all dust and harsh weather.
  • Standard Gray finish.
  • Easy to assemble, install and maintain.

Mechanical Dimensions

LED Street Light Housing MLT-SLH-AS-II Mechanical Dimensions

Parameter

Model No.LED Street Light Housing MLT-SLH-AS-II
Dimension of Housing49.7cm(L)*23cm(W)*7cm(H)
Fixture MaterialDie-casting Aluminum Alloy
Surface Finish ColorGray or Customized color
Material of DiffuserHigh Transmittance Tempered glass
Effective MCPCB Mounting Size250mm(L)*175mm(W)
Recommended LED Power30W to 80W
Driver Box Dimension150mm(L)*90mm(W)*50mm(H)
Pole MountingAccommodates up to Φ65mm pipe
Adjustable Slip FitterNot available
Standard PhotocellOptional
IP RatingIP65

Pictures

LED Street Light Housing MLT-SLH-AS-II Front View
LED Street Light Housing MLT-SLH-AS-II Front View
LED Street Light Housing MLT-SLH-AS-II Back View
LED Street Light Housing MLT-SLH-AS-II Back View

Packing Information

Net Weight3.42kg/PCS
Gross weight7.43kg/carton
Quantity2PCS/ carton
Carton Size52.5cm(L)*27cm(W)*22cm(H)

Application

This heavy-duty, modern design and cost-effective LED street light housing fixture is typically used as 30W-80W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
