Brief Introduction

This LED street light housing fixture MLT-SLH-AM-II is the medium size of SMD modular LED street light housing fixture from Moonlight LED street light A series. In this series, there are five different size, MLT-SLH-AS-II, MLT-SLH-AM-II, MLT-SLH-AL-II, MLT-SLH-AXL-II and MLT-SLH-AXXL-II. It comply with both normal 236mm*70mm LED modules, and Philips Fortimo FastFlex IP integrated LED modules. Modern uniformed LED modules design, precision die-casting molded and superior corrosion resistant coating finish frame with extruded aluminum module as LED lighting engine, make this housing can be used for variety of LED roadway lighting applications.

Feature

  • Durable aluminum alloy die-casting housing for heavy-duty outdoor lighting applications.
  • Individual and easy maintenance LED street light module as light engine.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • Rugged heavy gauge, 4 bolt, galvanized clamp with stainless steel hardware secures fixture to pole arm.
  • Separate LED light engine and driver box for easy maintenance.
  • Tool-less design for replace the LED driver without any tool.
  • Large driver box complies with different brand of LED drivers.
  • Silicon gaskets.
  • Adjustable knuckle slip fitter with stainless steel hardware secures fixture to pole arm.
  • Side-entry or post-top mounting. Universal mounting pieces allows precise adjustment on-site.
  • Standard Twist lock photocell mounting platform for lighting control.
  • Quick disconnection terminal block mounting platform for disconnect the power supply for linemen handling security.
  • IP65 rated, protect from all dust and harsh weather.
  • Standard Gray finish.
  • Easy to assemble, install and maintain.

Mechanical Dimensions

LED Street Light Housing MLT-SLH-AM-II Mechanical Dimensions

Parameter

Model No.LED Street Light Housing MLT-SLH-AM-II
Dimension of Housing70.4cm(L)*33.6cm(W)*15.3cm(H)
Fixture MaterialDie-casting and Extruded Aluminum Alloy
Surface Finish ColorGray or Customized color
Material of DiffuserHigh Transmittance PC Lenses
LED Module Size300mm(L)*70mm
Compatibility LEDsLumileds 3030 or similar LEDs
Lens size236mm(L)*70mm(W), 64PCS

270mm(L)*70mm(W), 60PCS

Lenses Degree70° × 140°
Recommended LED Power120W to 150W
Driver Box Dimension285mm(L)*125mm(W)*50mm(H)
Pole MountingAccommodates up to Φ60mm pipe
Adjustable Slip FitterYes, ±15°
Standard PhotocellOptional
IP RatingIP65

Pictures

LED Street Light Housing MLT-SLH-AM-II Front View
LED Street Light Housing MLT-SLH-AM-II Front View
LED Street Light Housing MLT-SLH-AM-II Back View
LED Street Light Housing MLT-SLH-AM-II Back View

Packing Information

Net Weight6.62kg/PCS
Gross weight7.84kg/carton
Quantity1PCS/ carton
Carton Size74cm(L)*38cm(W)*23.5cm(H)

Application

This heavy-duty, modern design and cost-effective modular LED street light housing fixture is typically used as 120W-150W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
