This LED street light case fixture MLT-SLH-FS-II is the small size of SMD LED street light housing fixture from Moonlight LED street light F series. In this LED street light shell family, there are also a smaller one MLT-SLH-FXS-II and bigger one MLT-SLH-FM-II in this series. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing with standard twist lock photocell mounting platform, make this LED street light housing can be used for variety of LED roadway lighting applications.
- Durable aluminum alloy die-casting LED street light enclosure for heavy-duty outdoor lighting applications.
- Ribbon-free and compact design.
- Easy drainage system.
- Separate LED light engine and driver box for easy maintenance.
- Tool-less design for replace the LED driver without any tool.
- Large driver box complies with variety of drivers and dimming options.
- Both cover and bottom of the driver box have the GND bosses for security.
- Plastic electrostatic spraying to resist corrosion, chipping and fading.
- Adjustable knuckle slip fitter help to adjust the led street light fixture on-site for optimal photometric performance, which make sure that the light distributions are specifically adapted to the real needs of the area to be lit.
- 5mm high light transmittance tempered glass diffuser.
- Silicon gaskets.
- SUS304 stainless steel bolts for fastening.
- The powder coated die-cast clips make it a harmonious overall with the rest of the luminaire.
- Twist lock photocell mounting platform for lighting control.
- Quick disconnection terminal block mounting platform for disconnect the power supply for linemen handling security.
- IP66 rated, protect from all dust and harsh weather.
- Standard sanded gray finish.
- Easy to assemble, install and linemen friendly maintain.
|Model No.||LED Street Light Housing MLT-SLH-FS-II|
|Dimension of Housing||58.3cm(L)*24.4cm(W)*12.0cm(H)|
|Fixture Material||Die-casting Aluminum Alloy|
|Surface Finish Color||Sanded Gray or Customized color|
|Material of Diffuser||High Transmittance Tempered glass|
|Effective MCPCB Mounting Size||164mm(L)*160mm(W)|
|Recommended LED Power||30W to 80W|
|Driver Box Dimension||180mm(L)*90mm(W)*70mm(H)|
|Pole Mounting||Φ50 or 60mm pipe|
|Adjustable Slip Fitter||-15°to +15°|
|Quick Disconnection Terminal Block||Optional|
This heavy-duty, modern design and cost-effective LED street light housing fixture is typically used as 60W-80W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
