LED High Bay Housing MLT-HBH-ES-II

LED High Bay Housing MLT-HBH-ES-II

LED High Bay Housing MLT-HBH-ES-II

LED High Bay Housing MLT-HBH-ES-II

Brief Introduction

This LED high bay housing fixture MLT-HBH-ES-II is the small size of round SMD LED high bay housing fixture from Moonlight LED high bay E series. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing, make this housing can be used for variety of LED commercial and industry lighting applications.

Feature

  • Durable aluminum alloy die-casting housing for heavy-duty lighting applications.
  • Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.
  • Easy drainage fins system.
  • Multiple brand power supplies compatibility.
  • Plastic electrostatic spraying to resist corrosion, chipping and fading.
  • High light transmittance tempered glass or PC Lens.
  • Silicon gaskets.
  • SUS304 stainless steel bolts and hook for fastening
  • IP65 rated, protect from all dust and harsh weather.
  • Standard black finish.
  • Multiple mounting solution for different installation applications.
  • Safety rope is provided for security.
  • Easy to assemble, install and linemen friendly maintain.

Mechanical Dimensions

led_high_bay_housing_mlt-hbh-es-II_2

Parameter

Model No.LED High Bay Housing MLT-HBH-ES-II
Dimension of Housing27.5cm(φ)*11cm(H)
Fixture MaterialDie-casting Aluminum Alloy
Diffuser MaterialHigh Transmittance Tempered glass/PC
Surface Finish ColorBlack or Customized color
Effective MCPCB Mounting Size185mm(Φ)
Recommended LED Power30W to 100W
Driver CompatibilityMultiple Brand
Beam Angle60°/90°/120°
Mounting MethodHook /Pendant /Bracket Mounting Options

Type of Mounting

Pictures

led_high_bay_housing_mlt-hbh-es-II_3
led_high_bay_housing_mlt-hbh-es-II_3
led_high_bay_housing_mlt-hbh-es-II_4
led_high_bay_housing_mlt-hbh-es-II_4

Different Type of Lenses

led_high_bay_housing_mlt-hbh-es-II_6
60° Lens LED High Bay Housing
led_high_bay_housing_mlt-hbh-es-II_7
90° Lens LED High Bay Housing
led_high_bay_housing_mlt-hbh-es-II_8
120° Lens LED High Bay Housing

Packing Information

Net Weight6.40kg
Gross weight6.70kg
Quantity4PCS/ carton
Carton Size28(L)*28cm(W)*55.5cm(H)

Application

This heavy-duty, modern design, energy-efficient and cost-effective LED high bay housing fixture is typically used as 30W-100W LED high bay light. LED high bay lights are specifically designed for taller ceilings and larger areas. They focus light more directly to create powerful illumination at a long range. This makes them perfect for commercial and industrial applications such as supermarkets, exhibition halls, big-box retail stores, sporting venues, manufacturing plants, warehouses, recreation centers, hangars and storage facilities. These LED industry lighting fixtures improve visibility and worker safety while enhancing productivity.
