Adjustable Knuckle Slip Fitter MLT-KSF-001
Adjustable Knuckle Slip Fitter MLT-KSF-001
Brief Introduction
Most modern LED road lighting and LED area lighting applications request the head of the lamp is adjustable. But with our adjustable knuckle slip fitter, you only need to focus on the CAD work of the light head and keep the necessary connection mounting holes on your design, which will save your cost of investment on the knuckle slip fitter for the connection of the pole. Most of the adjustable knuckle slip fitters on the market can only adjust around +/- 15˚, but with our adjustable knuckle slip fitter MLT-KSF-001, you can adjust that from – 90˚ to +90˚. What is more, the stainless bolts we are using is SUS304, not like the normal one on the market made from SUS201. Knuckle slip fitter MLT-KSF-001 is designed for heavy-duty LED lighting applications with dark bronze, gray, black and white finishing colors, and you can also choose any customized colors as you like. The polyester powder coating resist chipping and fading which make the fitter durable for outdoor environment.
Feature
- High-pressure die-casting knuckle slip fitter.
- Plastic electrostatic spraying powder coating to resist chipping and fading.
- Adjustable angle +/- 90˚.
- SUS304 stainless bolts.
Mechanical Dimensions
Parameter
| Model No. | Adjustable Knuckle Slip Fitter MLT-KSF-001 |
| Dimension of Knuckle Slip Fitter | 21.2cm(L)*11.8cm(W)*6.3cm(H) |
| Suitable Pole Size | Φ65mm |
| Main Material | Die-casting Aluminum |
| Surface Finishing | Polyester Powder Coating |
| Available Color | Dark bronze/Gray/Black/White |
Pictures
Packing Information
| Net Weight | 1.15kg/PCS |
| Gross weight | 36kg/Carton |
| Quantity | 30PCS/ carton |
| Carton Size | 40cm(L)*27cm(W)*32.5cm(H) |
Application
This knuckle slip fitter is die-casting mounting accessory designed for a single lighting fixture mounted onto a 65mm tenon. This incredibly durable slip fitter mount features an adjustable knuckle that allows for customized directional lighting in areas such as parking lots, street ways, and building facades. It is ideal for many architectural and landscape lighting applications.
